PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity

PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity
PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity

Large Image :  PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity

Product Details:
Place of Origin: Shandong, China
Brand Name: DEARTO
Certification: ISO9001
Model Number: DTS Series
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $1,700.00 - $6,500.00/sets
Packaging Details: Carton Packing
Supply Ability: 1000 Set/Sets per Month
Contact Now

PID Control Hot and Cold Fluid Thermostat Temperature Calibration Bath 0.01C Uniformity

Description
Warranty: 1 Year Classification: Laboratory Thermostatic Devices
Customized Support: OEM, ODM, OBM Resolution: 0.001℃
Horizontal Temperature Field Uniformity: <0.01℃ Vertical Temperature Field Uniformity: <0.01℃
Power Supply: 220VAC/50Hz

Products Description

Patented technology: The thermostatic bath has patented flameproof technology.

DTS series liquid thermostat is the ideal temperature constant temperature equipment for verifying and calibrating various low temperature thermocouple, industrial thermal resistance, pressure thermometer, bimetal thermometer, glass liquid thermometer and other temperature sensors. The bath body adopts the structure of lateral stirring in the design. The technical indicators of the temperature field in the working area meet the technical requirements of the temperature uniformity and temperature fluctuation of the thermostatic bath. At the same time, this series of liquid thermostatic bathes have simple operation and convenient use. Etc.
Product Features
1, The temperature field uniformity is good by using double bath side stirring mode.
2, Intelligent PID control, with excellent temperature field stability and uniformity;
3, High resolution display instrument, resolution 0.001℃.
4, Imported compressor, stable and reliable performance, optimized refrigeration system cooling speed faster.
5, RS232/RS484 communication interface selection, can achieve computer control.
6, Humanized design control is comfortable and convenient.
Product Paramenters
Product name
Hot thermostatic oil bath
Thermostatic water bath
Refrigeration thermostatic liquid bath
Model
DTS-300G
DTS-95G
DTS-01G
DTS-10G
DTS-30G
DTS-40G
DTS-60G
DTS-80G
Temperature range
70~300℃
PT+10~95℃
0~105℃
-10~105℃
-30~105℃
-40~100℃
-60~100℃
-80~100℃
Resolution radio
0.001℃
Working medium
Silicone oil
Soft water
Antifreeze oil
Absolute ethanol
Horizontal uniformity
≤0.01℃
Vertical uniformity
≤0.01℃
Temp fluctuation
±0.007℃
±0.01℃
Work area size
φ150×480mm
φ130×480mm
Volume (L)
23L
18.5L
Dimensions (mm)
660(L)×540(W)×1120(H)mm
700×590×1120
Max Power (KW)
3
2
2.8
3
Weight (Kg)
94
95
115
155
