Product Details:
|
| Warranty: | 1 Years | Customized Support: | OEM |
|---|---|---|---|
| Stability: | ±0.05℃/1 Year | Display Resolution: | 0.001℃ |
| Dimension Of Main Body: | 106mm*48mm*37mm | Weight: | 202g |
| Sensor Texture: | 316stainless Steel | Display: | LCD Screen |
| Power Supply: | Rechargeable Lithium Battery | Measuring Range: | -60℃-300℃ |
The best alternative to mercury thermometers
DTSW rod type standard (precision) digital thermometer, is the latest in the field of industrial temperature calibration, precision measurement, its accuracy and repeatability can be achieved better than 0.05 ℃ / year, lithium batteries don't need to replace the battery life long, easy to carry and intuitive readings, strong and durable. It can not only be used as a temperature standard in the laboratory, but also can provide reliable, accurate and high-precision temperature measurement in the industrial field.
n Accurate and reliable: excellent accuracy indexes, annual change is better than that of 0.05 ℃, the electric temperature less than 1 PPM / ℃
n Wireless communication: real-time data can be transmitted to the computer screen through wireless communication
n Curve display: computer software can display 32 thermometer real-time curves simultaneously
n Data recording: it can store the temperature measurement results of 16,000 bands
n Intelligent indication: trend indicator shows the trend of temperature change
n Zero mark: any zero mark, volatility, deviation value intuitive display
n Intelligent processing: the maximum, minimum and average values are directly calculated and displayed
n Unit conversion: K, ℃, ℉ can be arbitrary switching
n Display of resistance value: the resistance value of the sensor is displayed synchronously with the temperature value
n Regular shutdown: you can set the shutdown time from 1 minute to 48 hours
n Ultra low power consumption: no battery replacement for life
n Sampling adjustable: sampling cycle from 1S to 2H can be customized to facilitate timed sampling
n Clean and corrosion resistant: the probe of food grade 316 stainless steel is corrosion resistant and easy to clean
n Easy to charge: the charging port is compatible with the mobile phone, and any standard USB port can be easily charged
Wireless data transmission:
The Stick standardDigital Thermometer have wireless data transmission function, which can transmit the collected real-time data and historical data to the computer software remotely through 2.4G wireless communication, and analyze, process, save and export the data through the computer software. Intuitive and convenient use, the Stick Digital Thermometer won the favor of customers.
Wireless transmission application scenarios:
Wireless remote real-time reading temperature: remotely from the device under test, remotely read temperature values
Wireless data export
can read thermometer historical measurement data without connecting lines
Software function:
The digital thermometer management software can display the value collected by the digital thermometer to the computer in real time through wireless transmission. It can also read the internal history data of the thermometer to the computer, or read and display the historical data saved by the computer. The temperature curve of each thermometer is displayed in real time on the right side. The top can read the current mainstream desktop digital meter values for displaying standard temperature values.
Software features
n Multi-channel display: as many as 32 thermometers are collected in real time, and the maximum quantity can be expanded according to the user's demand
n Intelligent curve: The thermometer curve is displayed in real time on the right side, and the channel, color and thickness can be freely configured.
n Digital table support: support mainstream 5 1/2, 6 1/2, 7 1/2, 8 1/2 desktop digital table
n Standard support: support standard platinum resistance data calculation, just enter the value of the certificate can be used
n One-click readout: the historical temperature data saved by the thermometer can be read into the software
n Report export: the data collected from the thermometer can be exported to the EXCEL table for analysis
n Data import: it can import the historical data saved in the computer into the software to display the curve
n Target value marking: the target value can be set in the curve to view the heating and cooling time and curve of the constant temperature source
n Thermometer calibration: support up to 64 point difference calibration of the thermometer
n Battery display: The remaining battery value of each thermometer is displayed in real time, and the power of each thermometer is clear at a glance.
| Name | Standard (precision) digital thermometer | |
| Model | DTSW-1-A | DTSW-1-B |
| Temperature range | -60~160℃ | -60~300℃ |
| Accuracy | 0.04℃+0.005%FS | 0.05℃+0.01%FS |
| Calibration cycle | 1Year | |
| Main engine temperature coefficient | <1ppm/℃ | <1ppm/℃ |
| Length of sensor | 300mm,500mm(19.68 in) | |
| Sensor diameter | 6mm | |
| Sensor material | 316 stainless steel (medical, food grade) | |
| Sensor specification | Thin film platinum resistance | Wire wound platinum resistance |
| Sensor temperature coefficient | Rated value:0.00385 Ω/Ω/℃ | |
| Display resolution | 0.001℃ (the user can be configured to 0.1 ℃, 0.01 ℃) | |
| Sampling frequency | 0.5s, 1S and 2S can be configured | |
| Thermal response time constant | 30S | |
| Data storage | 16,000 sets of data (with time stamp) | |
| Communications | USB and wireless communication | |
| Wireless communication distance | No occlusion up to 160m | |
| The battery type | High temperature lithium battery | |
| Lithium battery life | No less than 2000 cycles of charge and discharge | |
| Lithium battery charging time | 2 hours | |
| Charging voltage | DC5V | |
| Preheating time | Preheat for 1 minute before use | |
| Working temperature of communication module | −20℃ - 60℃(14℉-122℉) | |
| Host working environment | −10℃ - 50℃(14℉-122℉) | |
| Main engine protection class | IP50 | |
| Sensor protection class | IP68 | |
| Host size (mm) | 106(L)X48(W)X37(H) | |
| Total weight | 202g | |
| Storage condition | −20℃-60℃(−4℉-140℉) 5%RH-80%RH(Without condensation) | |
