Product Details:
|
| Warranty: | 1 Year | Customized Support: | OEM, ODM, OBM |
|---|---|---|---|
| Generating Range: | Humidity 5%RH~95%RH | Uniformity: | Temperature ≤0.1℃; Humidity≤1%RH |
| Weight: | ≤14 Kg | Dimension Of Complete Generator: | 455 Mm X412mm X205mm |
| Color: | White | Power Supply: | 220VAC |
|
Nominal humidity range
|
5 %rh~95 %rh (20±3℃)
|
|
Nominal temperature range
|
5℃~50℃
|
|
Temperature stability
|
±0.05℃
|
|
Temperature uniformity
|
≤0.05℃(20±3℃) ≤0.1℃(5~50℃)
|
|
Max allowable temperature error
|
±0.05℃(20±3℃) ±0.1℃(5~50℃)
|
|
Humidity stability
|
±0.2 %RH
|
|
Humidity uniformity
|
≤0.3 %RH(20±3℃) ≤0.5%RH(5~50℃)
|
|
Max allowable error of relative humidity
|
±0.8 RH(20±3℃) ±1.5%RH(5~50℃)
|
|
Desiccant
|
Molecular sieve or discolored silica gel (renewable)
|
|
Saturated media
|
Distilled or deionized water
|
|
Cavity Workspace Dimensions
(length × width × height) |
Small TADT-1G 110 mm×110 mm×110 mm (appr. 1.3 L)
|
|
|
Standard TADT-2G 160 mm×175 mm×175 mm (appr. 5 L)
|
|
|
Extended TADT-3G 280 mm×175 mm×175 mm (appr. 9 L)
|
|
Sensor Test Window
|
Modular design, support customized on demand
|
|
Maximum opening diameter of test
|
60 mm
|
|
Maximum number of openings in test
|
15
|
|
Communication interface
|
RS232
|
|
General technical indicators
|
|
|
|
|
||||
|
Power requirements
|
220VAC±10 50Hz
|
|
|
|
||||
|
Power
|
750W
|
|
|
|
||||
|
Temperature range
|
Use
|
(5~35)℃
|
|
|
||||
|
|
Storage
|
(0~70)℃
|
|
|
||||
|
Humidity range
|
Use
|
(0~85)% rh
|
|
|
||||
|
|
Storage
|
(0~100)% rh
|
|
|
||||
|
Weight
|
20kg
|
|
|
|
||||
